Fly Ash Brick Making Machine

Machinery Collection

Explore our collection of fly ash brick machines, Fully Automatic Paver block machines, and Automatic Vibrator Machine, renowned worldwide for their high quality, innovative technology, and global export excellence.

Fully Automatic Fly Ash/Concrete Brick Making Machine - 12 Pcs

SLMW N004

Fully Automatic Fly Ash/Concrete Brick Making Machine - 12 Pcs

Approx Price: 1850000

This automated fly ash brick making machine features 4000 PSI hydraulic jacks and can produce 12 fly ash bricks in one operation. It requires 30 horsepower of electricity and 8-10 workers. This 12-piece brick-making machine can produce a variety of sizes including 9 "x 4" x 3 ". This 12-piece fly ash brick making machine can produce 20,000 bricks in about 8 hours.

A 400 kg capacity oil-fitted reduction gearbox with raw material mixing. A 1 piece conveyor is used to transport the mixed activation ingredients from the pan mixer to the press hopper. In addition, an 18-foot rubber conveyor belt is also attached to a frame with a 2-HP motor.

Enquire Now
Technical Specification
MACHINE Body Heavy Duty 1 Piece : M.s Fabricated Stationary Chassis Of Angles, Channels And Sheet Fitted With Hydraulic Jacks For Compression of up to 4000 PSI Hydraulically Operated Power Pack With10 Hp Ac Motor, Sweep, Oil Cooling System, And Plate Vibrating System With 2 Hp Vibrator
Power Pack : High Pressure, Low Pressure Pump, Control Valve, Relieve Valve, Pcm, Pressure Gauge, Pipe Line, Oil Tank Capacity 400 Litter, Plc Etc.
CAPACITY Fly Ash Brick - 12 Pcs. in One Operation.
Production : 20000 Pcs/8 Hrs
SIZE 9" x 4" x 3"
TOTAL POWER 30 HP
MEN POWER Total : 8 to 10 ( 1 person skilled )
FACILITY Facility Single Feeder Facilities For Production of Fly Ash Brick Superior Vibration in Brick Press.
PAN MIXER Pan mixer 2 Pieces : of 1500 mm diameter fabricated with structural mild steel with replicable inner fitted with 15 HP, oil fitted reduction gear box feeding hopper with a capacity to mix 450 kg raw material.
CONVEYOR BELT Belt Conveyor 1 Piece: to shift mixed activated raw material from pan mixer to the feeder bin of the press. The 18 feet rubber conveyor belt is mounted structurally fitted with 2 HP motors.
PALLET TRUCK Pallet Truck 2 Piece: To Lift The Raw Material And Stocks To One Place To Another Place, This Is A Manually Operated On Structural Mild Steel Chassis With Tires.
NOTE With Toolbox Free

Fully Automatic Fly Ash/Concrete Brick Making Machine - 10 Pcs

SLMW N005

Fully Automatic Fly Ash/Concrete Brick Making Machine - 10 Pcs

Approx Price: 1680000

This automated system can produce 14,000 fly ash bricks in 8 hours using hydraulic jacks at 3500 PSI compression. The 2 Piece Conveyor Belt transports active raw material from the pan mixer to the press feeder bin. This machine has a 400-liter oil capacity. This machine can make 10 pieces of fly ash bricks in a single operation with our fly ash brick making machine.

Two pallet trucks are needed to transport raw materials and stock from one location to another, and they are manually operated on a structural mild steel chassis with tires. This machine has an oil-fitted reduction gearbox feeding hopper with a 450 kg raw material mixing capacity.

Enquire Now
Technical Specification
MACHINE Body Heavy Duty 1 Piece : M.s Fabricated Stationary Chassis Of Angles, Channels And Sheet Fitted With Hydraulic Jacks For Compression Of Upto 3500 PSI Tons Hydraulically Operated Power Pack With10 Hp AC Motor, Sweep, Oil Cooling System, And Plate Vibrating System With 2 Hp Vibrator, Cycle Period 20 seconds to give output.
Power Pack : High Pressure, Low Pressure Pump, Control Valve, Relieve Valve, PCM, Pressure Gauge, Pipe Line, Oil Tank Capacity 400 Litter, Plc Etc.
CAPACITY Fly Ash Brick - 10 Pcs. in One Operation.
Production : 14000 Pcs/8 Hrs
SIZE 9" x 4" x 3"
PAN MIXER Pan mixer 2 Pieces : of 1500 mm diameter fabricated with structural mild steel with replicable inner fitted with 10HP, oil fitted reduction gear box feeding hoper with a capacity to mix 450 kg raw material.
CONVEYOR BELT Belt Conveyor 1 Piece: to shift mixed activated raw material from pan mixer to the feeder bin of the press. The 18 feet rubber conveyor belt is mounted structurally fitted with 2 HP motors.
PALLET TRUCK Pallet Truck 2 Piece: To Lift The Raw Material And Stocks To One Place To Another Place, This Is A Manually Operated On Structural Mild Steel Chassis With Tires.
NOTE With Toolbox Free

Fully Automatic Fly Ash/Concrete Brick Making Machine - 08 Pcs

SLMW N006

Fully Automatic Fly Ash/Concrete Brick Making Machine - 08 Pcs

Approx Price: 1560000

In 8 hours, this machine can make 12,000 fly ash bricks. It comes with a sheet-fitted 3000 PSI hydraulic compression system. The capacity of an oil-fitted reduction gearbox with raw material mixing is around 450 kg. This machine can create four bricks in one operation thanks to its plate vibrating technology.

One piece of the conveyor belt is used to transport the mixed activation ingredients from the pan mixer to the press hopper. It also requires two Pallet Trucks to transport the raw materials and inventories from one location to another.

Enquire Now
Technical Specification
MACHINE Body : Heavy Duty 1 Piece : M.s Fabricated Stationary Chassis Of Angles, Channels And Sheet Fitted With Hydraulic Jacks For Compression Of 3000 PSI Hydraulically Operated Power Pack With10 Hp AC Motor, Sweep, Oil Cooling System, And Plate Vibrating System With 2 Hp Vibrator, Cycle Period 20 seconds to giove output.
Power Pack : High Pressure, Low Pressure Pump, Control Valve, Relieve Valve, PCM, Pressure Gauge, Pipe Line, Oil Tank Capacity 400 Litter, PLC Etc.
CAPACITY Fly Ash Brick - 8 Pcs. in One Operation.
Production : 12000 Pcs/8 Hrs
SIZE 9" x 4" x 3"
PAN MIXER Pan mixer 2 Pieces : of 1500 mm diameter fabricated with structural mild steel with replicable inner fitted with 10 HP, oil fitted reduction gear box feeding hopper with a capacity to mix 450 kg raw material.
CONVEYOR BELT Belt Conveyor 1 Piece: to shift mixed activated raw material from pan mixer to the feeder bin of the press. The 18 feet rubber conveyor belt is mounted structurally fitted with 2 HP motors.
PALLET TRUCK Pallet Truck 2 Piece: To Lift The Raw Material And Stocks To One Place To Another Place, This Is A Manually Operated On Structural Mild Steel Chassis With Tires.
NOTE With Toolbox Free

Fully Automatic Fly Ash/Concrete Brick Making Machine - 06 Pcs

SLMW N007

Fully Automatic Fly Ash/Concrete Brick Making Machine - 06 Pcs

Approx Price: 1450000

This automated fly ash brick making machine has hydraulic jacks for 2500 PSI compression and can create 6 bricks per stock. 1 piece of 1500 mm diameter mild steel shell mixer with a repeatable interior with 7.5 horsepower is used.

An oil-fitted reduction gearbox with raw material mixing has a capacity of roughly 450 kg and a 300-liter oil tank capacity. The belt conveyor 1 piece is also to transport mixed active raw material from the pan mixer to the press’s feeder bin.

Enquire Now
Technical Specification
MACHINE Body Heavy Duty 1 Piece : M.s Fabricated Stationary Chassis Of Angles, Channels And Sheet Fitted With Hydraulic Jacks For Compression Of 2500PSI Hydraulically Operated Power Pack With 7.5 HP AC Motor, Sweep, Oil Cooling System, And Plate Vibrating System With 1 Hp Vibrator.
Power Pack : High Pressure, Low Pressure Pump, Control Valve, Relieve Valve, PCM, Pressure Gauge, Pipe Line, Oil Tank Capacity 300 Litter, PLC Etc.
FACILITY Single Feeder Facility For Productionnof Fly Ash Brick.
CAPACITY 6 Brick Per Stocks (10000)
PAN MIXER Pan mixer 1 Pieces : of 1500 mm diameter fabricated with structural mild steel with replicable inner fitted with 7.5 HP, oil fitted reduction gear box with a capacity to mix 450 kg raw material.
CONVEYOR BELT Belt Conveyor 1 Piece: to shift mixed activated raw material from pan mixer to the feeder bin of the press. The 18 feet rubber conveyor belt is mounted structurally fitted with 2 HP motors.
PALLET TRUCK Pallet Truck 2 Piece: To Lift The Raw Material And Stocks To One Place To Another Place, This Is A Manually Operated On Structural Mild Steel Chassis With Tires.
NOTE With Toolbox Free

The construction industry is changing rapidly with new technologies and architectural styles. In addition to new approaches, new building materials are being introduced daily. One such material that has become increasingly popular in recent years is known as fly ash. In construction, fly ash bricks are commonly utilized.

Fly ash bricks are less expensive than typical clay bricks and have various secondary benefits. A high-tech advanced fly ash brick making machine is required for producing robust fly ash bricks.

Fly ash bricks-making machine allows you to complete a large amount of work quickly and easily generate all of the bricks you require. Different types of fly ash brick making machines are available with different brick making capabilities.

Now that we've understood the basics of Fly ash bricks making machines, let's take a look at the four types of machines used to make fly ash bricks.

ISO Certified Company

Best Quality

24/7 Support

Client Satisfaction

How Do These Machines Produce Bricks?

The device called Fly Ash Bricks Machine creates bricks from fly ash, lime, and gypsum. These devices compress the raw materials into the required brick shape and size using hydraulic pressure. They are available in many versions with output capacities ranging from 800 to 1600 bricks per hour.

The best fly ash bricks machine manufacturers in India, Gujarat, Morbi has the fly ash bricks machine, which employs industrial waste byproducts like fly ash, a byproduct of coal-fired power plants, is an environmentally beneficial substitute for conventional clay bricks. This makes it a very sustainable solution because it lowers the need for fertile land and protects the environment.

The device works by mixing the raw components, forming them into bricks, and then letting them dry in the sun. The material is uniformly compressed by the hydraulic pressure, producing strong bricks that are resistant to heat, water, and termites.

It is crucial to remember that the calibre of the raw materials used has a significant impact on the quality of the bricks produced. To make strong, long-lasting bricks, the machine needs high-quality fly ash, lime, and gypsum. Therefore, it is essential to buy raw materials from trustworthy vendors.

Due to its low water absorption, exceptional insulating qualities, and less need for cement and plastering, fly ash bricks are extremely cost-effective. They are a well-liked option among both builders and homeowners because they are very simple to install and require less maintenance.

The Advantages of Fully Automatic Fly Ash Brick Machine

Purchasing a fly ash brick producing equipment can help you save money if your company uses fly ash bricks. Making your own bricks is now possible thanks to this machine, which is also quite simple to operate. A fully automatic fly ash brick making machine is incredibly effective and enables you to produce a lot of bricks. When you get one of these devices, you won't need to purchase bricks any longer and you may save a lot of money.

This fly ash brick producing machine will help you produce a large number of bricks in a short period of time, giving you more control over your business. This machine may be put to a number of different applications and will help you accomplish a lot of tasks. Once you understand how to operate the machine, you can start creating bricks right away. The bricks may be used to build a multitude of different objects and are incredibly robust and long-lasting. When you make your own bricks, you save a lot of money and won't have to pay someone to buy them.

The brick-making equipment is robust and capable of producing a large number of bricks. The equipment requires little maintenance and is built to last for a long time with little effort. You can complete a lot of work fast and easily with the brick moulding machine. When you invest in one of these devices, you will be able to complete a lot of work quickly and discover what you need with ease. When you have a machine you can rely on, getting things done will be quite simple and can help you accomplish a lot. The finest machine will fit within your budget and will include all the functions you require. Make sure to look at this piece of machinery if you require an interlocking brick machine you can rely on.

Knowing every detail about the machine will make it simpler for you to select the appropriate model and locate the items you require. The device is relatively simple to operate and can be useful in a number of ways. Finding the ideal model for your company will be simple once you know what machine you require.

Selecting the Ideal Manufacturer for Fly Ash Bricks Machine

Due to their cost- and eco-effectiveness, fly ash bricks have become more popular in the construction sector. Machines for producing fly ash bricks are essential in the manufacture of these bricks. However, selecting the best machine manufacturer might be challenging given the wide range of models and manufacturers on the market. To know the best fly ash concrete and cement bricks making machine suppliers, you also need to know the ideal manufacturer so that your business requirements are taken care effectively.

The machine's production capacity is one of the main factors to take into account. Determine how many bricks you must manufacture each day or each week based on the projects you are working on. Select a device with a production capacity that satisfies your needs.

The fly ash brick-making machine's level of automation can have a big impact on productivity and personnel costs. Automatic fly ash brick making machine manufacturers may perform a variety of duties, from material feeding through brick creation and stacking, with fully automated machinery. Semi-automatic machines, on the other hand, might require more manual effort. The endurance and structural integrity of the fly ash bricks depend heavily on the quality of the material. Examine the technology and features of the machine to make sure that bricks are produced consistently and at a high standard.

Electricity is used by the machines that make fly ash bricks, thus it is important to take this into account. To reduce operational costs, choose a manufacturer who create energy-efficient machinery. Lower electricity usage has a positive influence on the environment as well as financial savings.

Things to Consider When Purchasing Fly Ash Bricks Machine

Due to its durability, affordability, and environmental friendliness, fly ash bricks have gained popularity as an alternative to conventional clay bricks. The need for fly ash bricks has grown dramatically in recent years, spurring the creation of numerous types of fly ash brick machines. The following are a few of the fly ash brick machines that are most frequently used:

The most common type of fly ash brick machine is the automatic one, and it uses PLC control technology. It creates bricks with exceptional efficiency and accuracy, coming in a variety of sizes and forms. Fully automatic, this device takes very little manual labour.

A partially automated fly ash brick making machine: This machine also needs some manual labour. Raw materials must be loaded and finished bricks must be taken out of the moulds by operators. This machine is less expensive and more suited for small-scale production than the fully automatic one.

A hydraulic fly ash brick machine is renowned for its high production capacity and hydraulic pressure mechanisms. Less water is used to create high-quality bricks, increasing their strength and toughness.

Clay brick machine: This machine is specifically made to turn fly ash into clay bricks. To create bricks with a high degree of strength and texture, it combines fly ash, cement, and clay.

Paver block machine: This device can make a variety of concrete blocks, such as paver blocks and fly ash bricks. The machine, which creates blocks of various sizes and forms, is totally automatic.

The simplest type of fly ash brick machine, a manual one demands the most manual labour. It is perfect for low-volume manufacturing and straightforward brick-making processes.

In conclusion, fly ash bricks are an economical and environmentally friendly substitute for conventional clay bricks. The various fly ash brick machines are designed to meet the varying production requirements of various businesses. Manufacturers should take into account elements like production capacity, automation needs, raw material accessibility, and cost when choosing a fly ash bricks machine.

FAQS

Fly ash bricks are a more environmentally friendly alternative to red clay bricks. They are made from fly ash emitted by thermal power plants. They are a sustainable option and contain less harmful materials than other bricks. They are also more durable and strong than red clay bricks.

Bricks are an important building material that is typically available in a rectangular shape and are made of clay. In India, various types of bricks are manufactured, including clay bricks, fly ash bricks, and concrete bricks, among others.

Brick making machines are essential for construction companies to make bricks. Brick making machine prices in India can range from 20,00,000 to 60,00,000 depending on their features. Installation, transportation, and GST are all additional costs in addition to this machine's prices.
